ThermoWorks Square Dot

ThermoWorks Square Dot

Regular price $69.95 USD
Regular price Sale price $69.95 USD
Sale Sold out

Low stock: 2 left

This item is only available for purchase in our physical retail store. If you have questions about this item, please call us at 406-534-8427.

Grills, smokers, and ovens rarely display the real internal temperature. See your appliance's true performance. Square DOT's Average Mode automatically calculates the 15-minute running average temperature so you can control your cook every time.

A refreshing twist on a classic, Square DOT is everything you love about DOT only now with 2 channels and an amazing new air temperature average function. Channel 1 functions as a regular alarm thermometer while Channel 2 can operate in two different modes. Average mode shows you a revolving average temperature calculation of the last 15 minutes, starting when the alarm is first reached. It’s perfect for determining your average oven temperature as you cook, so you can adjust in realtime to get the most accurate results for any recipe. When average mode is disabled, Channel 2 will function as an alarm channel . Like DOT, Square DOT has big, easy-to-read digits, backlit display, ThermoWorks’ signature molded-in splash-proof seals and a commercial-grade plastic body making it a durable, user-friendly tool. It comes with a fold-out stand, a magnetic back for surface mounting, a Pro-Series® penetration probe, and a Pro-Series air probe—each with cables that withstand 700°F (371°C). Square DOT also accepts any of the optional Pro-Series probes. Intended for commercial food service, Square DOT beats houseware brands for simplicity and durability.

Two Channels
Measure both your food and the cooking environment with Average Mode OR set two high alarms to track two different foods while they cook.

Unbeatable Simplicity
Like with DOT, just press the Up and Down buttons to set your High Alarms for each channel. Press ANY button to activate the backlight.

Super-Rugged
Molded-in seals protect against spills, splashes, and rain. With the reinforced frame and 5,000 hours of battery life, Square DOT will be ready when you need it.

Verified Accuracy
Each Square DOT comes with its own NIST-traceable calibration certificate verifying its accuracy to national standards.

Probe Range -58 to 572°F (-50 to 300°C)
Cooking Probe Cable Range Max 700°F (370°C)
Accuracy ±1.8°F (±1.0°C) from -4 to 248°F (-20 to 120°C)
±3.6°F (±2.0°C) from -58 to -4°F / 248 to 392°F (-50 to -20°C / 120 to 200°C)
±5.4°F (±3.0°C) from 392 to 572°F (200 to 300°C)
Max Sounds Volume 70dB
IP Rating IP66
Operating Range 32 to 122°F (0 to 50°C)
Backlight 10 seconds
Resolution 1°F (°:C)
Units °C/°F switchable
Sensor Thermistor
Battery 2 x AAA, up to 5000 hours (1 year typical depending on alarm use)
Certificate Includes NIST-traceable calibration certificate



Pro-Series High Temp 4.5-inch Straight Penetration Probe (included)
Cable Max Temp 700°F (370°C)
Transition Max Temp 644°F (340°C)
Transition Dimensions 1.4 L x 0.35 inches dia. (35.6 L x 8.9 mm dia.)
Probe Range -58 to 572°F (-50 to 300°C)
Cable Length 47 inches (1.2m)
Probe Dimensions 4.5 L x 0.13 inches dia. reduces to 0.08 inches dia.
(114.3 L x 3 mm dia. reduces to 2 mm dia.)



Pro-Series High Temp Air Probe & Grate Clip (Included)
Cable Max Temp 700°F (370°C)
Transition Max Temp 644°F (340°C)
Transition Dimensions 1.4 L x 0.35 inches dia. (35.6 L x 8.9 mm dia.)
Probe Range -58 to 572°F (-50 to 300°C)
Cable Length 47 inches (1.2m)
